5 ELECTRICAL INSTALLATION
80
8023994-17I6/2020-03-19|SICK
ORIGINAL OPERATING INSTRUCTIONS| VMS4100/5100
Subject to change without notice
5.5 Connection for the LFT display (set up at the factory)
5.5.1 Cabinet without Ethernet switch
Fig. 79: Connection for the LFT display on the SIM2000 system controller / power supply unit
1 Ethernet data cable
Connection on LFT display Port on SIM2000
ETHERNET (X118) X11
2 Voltage supply
Wire color Connection on power supply unit (ML50.100)
Brown +
Blue -
Yellow-green
Tab. 13: Connection for the LFT display on the SIM2000 system controller / power supply unit
