Fig. 40: MID - information labels for the VMS5100 in “Touching/Side-by-Side” operating mode
with dynamic scale value switchover and affixed type labels
Legend
1
Identification label for scale interval value 1
(for “Touching/Side-by-Side” operating mode)
2
Identification label for scale interval value 2
3 Metrology information label with affixed type label
