Phoenix article number Description
2905470 Surge arrestor FLT-SECT1+T2-3S-350/25-FM: with separate PE and
N (L1, L2, L3, PE, N)
13.D.2.2 Shield Connection Clamps
Shield connection clamps for EMC busbar and for motor/power or measuring system
connection of the devices
Phoenix article number Name Connection method Tightening torque
3025163 SK 8 Screw connection (M4) max. 0.6 Nm
3025176 SK 14 Screw connection (M4) max. 0.8 Nm
3025189 SK 20 Screw connection (M4) max. 0.8 Nm
3026463 SK 35 Screw connection (M5) 1.5 to 1.8 Nm
Alternatively you can use WAGO terminals (see WAGO Shield Connection Clamps,
page 112).
13.D.3 TOSHIBA - Fiber Optic Connectors
http://www.toshiba.com
13.D.4 WAGO Innovative Connections
http://www.wago.com
13.D.4.1 Shield Connection Clamps
Shield connection clamps for EMC busbar and for motor/power connection of the
devices
WAGO article number
Description
791-111 Diameter of connectable conductor; 5 to 11 mm; height max. 47 mm;
17 mm wide (corresponds to SK 14 by Phoenix Contact)
791-117 Diameter of connectable conductor; 10 to 17 mm; height max. 63 mm;
23 mm wide (corresponds to SK 20 by Phoenix Contact)
For an alternative solution see Phoenix Shield Connection Clamps, page 112
Appendix D: Manufacturers
W
112 Drive System SD2S - Hardware Description 0362X49xy / 0362129xy
13.D
