11.2.4 Cables for the External Ballast Resistor
The cables of the external ballast resistor of R
EX
and +UB must be twisted. If the cable
is longer than 20 cm a shielded cable must be used.
General Information Regarding the Wiring
W
94 Drive System SD2S - Hardware Description 0362X49xy / 0362129xy
11
