The number of bus nodes is also limited by the specification according to ISO 11898.
The limiting value is between 32 and 100 bus nodes. depending on the used cable and
transmission rate. For further information on the maximum number of bus nodes refer
to the document “CAN Physical Layer” by the user organization CiA e. V.
8.9 X26/X27 – SERVOLINK
8.10 X44 – Power Supply
1-phase power supply of the device variants 0362x29xC / 0362x49xC
3-phase power supply of the device variants 0362x29xC / 0362x49xC
3-phase power greater than 3 × 230 V
AC
is only possible with a mains trans‐
former.
W
Connection Examples
Drive System SD2S - Hardware Description 0362X49xy / 0362129xy 75
8
