2 General Information
This manual describes the drive amplifiers 0362X49xy and 0362249xy (Light variant)
of the series SD2S. These devices allow operation of high-dynamic servo motors as
well as synchronous and asynchronous high-frequency spindles.
The devices are equipped with interfaces for different sensor systems allowing to drive
motors with resolvers as well as SinCos, EnDat, Hall, linear Hall, incremental and field
plate sensors. Motor systems without any sensors are also supported, whereas
different customized control methods are available. In addition, the devices can drive
rotary and linear motors. Thus, the number of device variants is reduced for the
machine manufacturer.
For real-time requirements the device variant 0362249xy comes with EtherCAT slave
interface.
The devices are designed according to the standard UL 61800-5-1.
This manual provides information on:
▶ Safety instructions and application advice
▶ Notes about the electromagnetic compatibility
▶ Description of the device (block diagram, type plate, module designation)
▶ Technical data, dimensions
▶ Connector pin assignment
▶ Wiring examples
▶ Status and error messages
▶ General information regarding the wiring (cables and line cross-sections)
▶ External protection, ballast circuit
This manual has the following demands on the trained staff of machine manufacturers:
Transport: only by skilled employees familiar with handling electrostatically
sensitive components.
Installation: only by experts with electromechanical experience
Initial operation: only by experts with experience in the fields of electrical engi‐
neering / drive technology
Information concerning the initial operation and parameterization of the
digital drive amplifier can be found in the manual of the software
drive‐
master2
.
You can download more documentation from the SIEB & MEYER website
under http://www.sieb-meyer.de/downloads.html.
2.1 Approval for the Markets in USA and Canada
Using products in public buildings or industrial environments in the USA or Canada
must be conform withe the applicable national regulations. In particular electric prod‐
ucts and machines are subject to testing and certification obligations and shall be
labeled specifically.
The Occupational Safety and Health Administration (OSHA) only accepts devices that
have been approved by an authorized NRTL laboratory (Nationally Recognized Testing
Laboratory) and labeled with an appropriate test mark. An NRTL authorized by OSHA
checks the legitimate status of the test mark by inspectors of the manufacturing sites,
for example.
W
General Information
Drive System SD2S - Hardware Description 0362X49xy / 0362129xy 13
