14 Index
0-9
0362129xy
31
0362149xy 31
0362249xy 31
050201 111
7-segment display 82
A
Accessories 109
B
Block diagram
27
C
Cable requirements 89
Click & Lock connectors 37
Connectors 35
D
Dimensions
32
E
Error messages 83
EtherCAT
connection 52
LED description 81
F
Firmware 105
G
Grounding
78
H
Housing ground
78
I
ID switch 37
Initial Operation 79
L
LED status display
81
Line cross-sections 90
Line filters
110
M
Mains chokes
89
Manufacturers 109
Motor cable 92
Mounting 32
O
Operating states 82
Optical filer connector (POF)
preparation of optical fiber cables
with connector 49
P
Push-in technology
37
Q
Quick stop messages 88
R
Residual current device (RCD)
22
Restart lock 95
RJ45 cable 93
S
Shielding of motor cable 77
Status display 81 , 82
STO (Safe Torque Off) 95
