Device variant EF IF EC IC
Overvoltage category II II
IP Code IP20 IP20
Degree of pollution 2 2
Max. weight 3,8 kg 3,8 kg
(1)
The logic voltage is necessary to maintain the error messages.
(2)
At a ballast power of 40 W the maximum rated current of the output stage is
12.5 A
rms
(14 A
rms
− 10.4 % = 12.5 A
rms
).
Rated current derating
Drive function SERVO SVC; VF-PWM
PWM frequency [kHz] 8 16 8 16
EF/IF rated current S1 [A
rms
] 14 10 14 10
EC/IC rated current S1 [A
rms
] 20 14 20 14
Device Description
W
34 Drive System SD2S - Hardware Description 0362X49xy / 0362129xy
