Digital modules
3.18 Digital output module SM 322; DO 32 x 120/230 VAC/1 A; (6ES7322-1FL00-0AA0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
3-53
Technical data
Current consumption
• from the backplane bus
• from load voltage L1 (no-load)
max. 190 mA
max. 10 mA
Power loss of the module typ. 25 W
Status, interrupts, diagnostics
Status display green LED per channel
Interrupts No
Diagnostics functions
• Group error display
Yes
red LED (SF)
Actuator selection data
Output voltage
• with "1" signal
min. L1 (-0.8 V)
Output current
• with "1" signal
Rated value
Permissible range
Permitted inrush current (per group)
1 A
10 mA to 1 A
10 A (for 2 AC scan cycles)
• leakage current at "0" signal
max. 2 mA
Output delay (resistive load)
• at "1" to "0"
1 AC cycle
• at "1" to "0"
1 AC cycle
Blocking voltage
zero transition
max. 60 V
Size of the motor starter max. size 4 to NEMA
Lamp load max. 50 W
Wiring two outputs in parallel
• for redundant load control
supported (only outputs of the same group)
• for performance increase
not supported
Control of a digital input supported
Switching frequency
• with resistive load
• with inductive load to IEC 947-5-1, AC 15
• with lamp load
max. 10 Hz
max. 0.5 Hz
1 Hz
Short circuit-proof output No
Wiring the actuators with 20-pin* front connector
*The necessary front connection version is needed twice here
