Analog modules
6.12 Analog output module SM 332; AO 4 x 16 bit; isochronous; (6ES7332-7ND02-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-107
6.12 6.12 Analog output module SM 332; AO 4 x 16 bit; isochronous;
(6ES7332-7ND02-0AB0)
Order number
6ES7332-7ND02-0AB0
Properties
4 outputs in 4 channel groups
The output channels can be programmed as
Voltage output
Current output
Resolution 16 bits
Isochronous mode supported
Supports the "CiR" function
Programmable diagnostics and diagnostic interrupt
electrical isolation between:
backplane bus interface and analog output channel
analog output channels
analog output and L+, M
Backplane bus circuit and L+, M
Diagnostics
For information on diagnostics message consolidated at the "group diagnostics" parameter,
refer to the table
Diagnostics messages of analog output modules
.
Terminal assignment
The following diagrams show wiring examples.
Note
When you switch the rated load voltage (L+) off and on, the output may carry incorrect
interim values for the duration of for approx. 10 ms.
