Digital modules
3.34 Digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A; programmable (6ES7327-1BH00-0AB0)
S7-300 Automation System Module data
3-120 Manual, 08/2006, A5E00105505-04
3.34 3.34 Digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A; programmable
(6ES7327-1BH00-0AB0)
Order number
6ES7327-1BH00-0AB0
Properties
Properties of SM 327; DI 8/DO 8 x DC 24 V/0.5 A:
● 8 digital inputs, plus 8 separately programmable inputs/outputs, electrically isolated in
groups of 16
● Rated input voltage 24 VDC
● Inputs suitable for switches and 2-/3-/4-wire proximity switches (BEROs)
● Output current 0.5 A
● Rated load voltage 24 VDC
● Outputs suitable for solenoid valves, DC contactors and indicator lights
● Dynamic change of parameters in RUN (CiR-compatible), separately at each channel.
● Readback of outputs.
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24-V power supply to SM 327; DI 8/DO
8 x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of approx. 50 µs, due to
the circuit structure.
