Digital modules
3.27 Digital output module SM 322; DO 8 x AC 120/230 V/2 A ISOL (6ES7322-5FF00-0AB0)
S7-300 Automation System Module data
3-88 Manual, 08/2006, A5E00105505-04
Technical data
Minimum load current 10 mA
Zero transition max. 60 V
Size of the motor starter max. size 5 to NEMA
Lamp load max. 50 W
Wiring two outputs in parallel
• for redundant load control
supported (only outputs of the same group)
• for performance increase
not supported
Control of a digital input supported
Switching frequency
• with resistive load
• with inductive load to IEC 947-5-1, AC 15
• with lamp load
max. 10 Hz
max. 0.5 Hz
max. 1 Hz
Short circuit-proof output Fuse, 8 A/250 V; per group
• Fuse-tripping current
min. 40 A
• Response time
max. 300 ms
Replacement fuses
• Wickman
• Schurter
• Littelfuse
8 A fuse/fast-blow
194-1800-0
SP001.1013
217.008
Fuse holder
• Wickman
653 07
Wiring the actuators with 20-pin front connector
1)
The load current must not be half-wave
2)
Potential errors are:
- No load voltage
- Fuse defective
3.27 3.27 Digital output module SM 322; DO 8 x AC 120/230 V/2 A ISOL
(6ES7322-5FF00-0AB0)
Order number
6ES7322-5FF00-0AB0
Properties
Properties of digital output module SM 322; DO 8 x AC 120/230 V/2 A ISOL:
● 8 outputs, electrically isolated
● Group error display
● Channelspecific status LEDs
● Programmable diagnostics
● Programmable diagnostic interrupt
● Programmable substitution value output
● Output current 2 A
● Rated load voltage 120/230 VAC
● Suitable for AC solenoid valves, contactors, motor starters, FHP motors and signal lamps
