Page #460 background imageLoading...
Page #460 background image
Parameter sets of signal modules
A.11 Parameters of analog IO modules
S7-300 Automation System Module data
A-40 Manual, 08/2006, A5E00105505-04
Output type and output range
The table lists the output types/ranges of SM 332; AO 8 x 12 Bit, including their codes. Enter
these codes at bytes 2 to 9 in data record 1 (refer to the previous figure.)
Table A-31 Output range codes of analog output module SM 332; AO 8 x 12 Bit
Output type Code Output range Code
Disabled 2#0000 Disabled 2#0000
Voltage 2#0001 1 V to 5 V
0 V to 10 V
± 10 V
2#0111
2#1000
2#1001
Current 2#0010 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
2#0010
2#0011
2#0100
A.11 A. 11 Parameters of analog IO modules
Parameters
The table below lists all parameters you can set for analog IO modules.
The comparison illustrates the editable parameters:
in
STEP 7
using SFC 55 "WR_PARM"
Parameters set in
STEP 7
can also be transferred to the module using SFC 56 and SFC 57
(refer to the
STEP 7
manuals).
Table A-32 Parameters of analog IO modules
Programmable, using ...
Parameters Data record number
... SFC 55 ... PG
Measuring method Yes Yes
Measuring range Yes Yes
Integration time Yes Yes
Output type Yes Yes
Output range
1
Yes Yes
