Digital modules
3.25 Digital output module SM 322; DO 8 x DC 48-125 V/1.5 A; (6ES7322-1CF00-0AA0)
S7-300 Automation System Module data
3-82 Manual, 08/2006, A5E00105505-04
3.25 3.25 Digital output module SM 322; DO 8 x DC 48-125 V/1.5 A;
(6ES7322-1CF00-0AA0)
Order number: "Standard module"
6ES7322-1CF00-0AA0
Order number: "SIPLUS S7-300 module"
6AG1 322-1CF00-2AA0
Properties
Properties of SM 322; DO 8 x DC 48-125 V/1.5 A:
● 8 outputs, with reverse polarity protection, and electrically isolated in groups of 4
● Output current 1.5 A
● Rated load voltage 48 VDC to 125 VDC
● suitable for solenoid valves, DC contactors and signal lamps
● Group error display (SF)
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the power supply, the outputs of SM 322; DO
8 x DC 48-125 V/1.5 A will carry a "1" signal for the duration of approx. 50 µs due to the
circuit structure.
