Analog modules
6.6 Analog input module SM 331; AI 8 x 13 Bit;(6ES7331-1KF01-0AB0)
S7-300 Automation System Module data
6-38 Manual, 08/2006, A5E00105505-04
6.6 6.6 Analog input module SM 331; AI 8 x 13 Bit;(6ES7331-1KF01-0AB0)
Order number
6ES7331-1KF01-0AB0
Properties
● 8 inputs in 8 channel groups
● Resolution adjustable per channel group (12 bits + sign)
● Measuring method adjustable per channel group:
– Voltage
– Current
– Resistance
– Temperature
● Any measuring range selection per channel
Terminal assignment
The following diagrams show wiring examples. Basically, these connection examples apply
to all channels (channel 0 to 7).
Note
When connecting voltage and current transducers, make sure the maximum permitted
common-mode voltage C
MV
of 2 V is not exceeded between the inputs. To prevent
measuring errors, interconnect the various M- terminals.
