Digital modules
3.33 Digital IO module SM 323; DI 8/DO 8 x DC 24 V/0.5 A; (6ES7323-1BL01-0AA0)
S7-300 Automation System Module data
3-116 Manual, 08/2006, A5E00105505-04
3.33 3.33 Digital IO module SM 323; DI 8/DO 8 x DC 24 V/0.5 A;
(6ES7323-1BL01-0AA0)
Order number: "Standard module"
6ES7323-1BH01-0AA0
Order number: "SIPLUS S7-300 module"
6AG1 323-1BH01-2AA0
Properties
Properties of SM 323; DI 8/DO 8 x DC 24 V/0.5 A:
● 8 inputs, electrically isolated in groups of 8
● 8 outputs, electrically isolated in groups of 8
● Rated input voltage 24 VDC
● Rated load voltage 24 VDC
● Inputs suitable for switches and 2-/3-/4-wire proximity switches (BEROs)
● Outputs suitable for solenoid valves, DC contactors and indicator lights
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24-V power supply to SM 323; DI 8/DO
8 x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of approx. 50 µs, due to
the circuit structure.
