Analog modules
6.2 Module overview
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-7
6.2.3 Analog IO modules:
Overview of properties
The table below shows the essential properties of analog IO modules
Table 6-4 Analog IO modules: Overview of properties
Properties SM 334; AI 4/AO 2 x 8/8 bits
(-0CE01-)
SM 334; AI 4/AO 2 x 12 bits
(-0KE00-)
Number of inputs 4 inputs in 1 channel group 4 inputs in 2 channel groups
Number of outputs 2 outputs in 1 channel group 2 outputs in 1 channel group
Resolution 8 bits 12 bits + sign
Measuring method adjustable for each channel group:
Voltage
Current
adjustable for each channel group:
Voltage
Resistance
Temperature
Output type each separate channel:
Voltage
Current
each separate channel:
Voltage
Supports isochronous mode No No
Programmable diagnostics No No
Diagnostic interrupt No No
Limit value monitoring No No
Hardware interrupt when limit
exceeded
No No
Hardware interrupt at end of cycle No No
Substitution value output No No
Potential ratios
electrically interconnected to
backplane bus interface
electrically isolated to load voltage
electrically isolated to:
backplane bus interface
load voltage
Special features Not programmable, measurement and
output type defined by hardwiring
-
