Analog modules
6.12 Analog output module SM 332; AO 4 x 16 bit; isochronous; (6ES7332-7ND02-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-113
6.12.2 Adjustable parameters
Introduction
For general information on programming analog modules, refer to the chapter
Programming
analog modules
.
The table below provides overview of configurable parameters and defaults.
Table 6-35 Summary of parameters SM 332; AO 8 x 12 Bit
Parameters Range of values Default Parameter
type
Scope
Enable
• Diagnostic interrupt
Yes/no
No
Dynamic
Module
Diagnostics
• Group diagnostics
Yes/no
No
static
Channel
Output
• Output type
• Output range
disabled
Voltage
Current
See table of
Output ranges for SM 332;
AO 4 x 16 bit
V
± 10 V
Dynamic Channel
Reaction to CPU STOP ASS
HLV
Outputs zero
current/voltage
Hold last value
ASS Dynamic Channel
Assigning parameters to channels
The parameters can be set separately at each output channel of SM 332; AO 4 x 16 Bit. You
can thus assign individual parameters to each output channel.
Assign the parameters you set at the SFCs in your user program to channel groups. Each
output channel of SM 332; AO 4 x 16 Bit is thus assigned to a channel group, i.e. output
channel 0 > channel group 0, for example.
Note
The output may carry incorrect interim values if you modify output ranges while SM 332; AO
4 x 16 Bit is in RUN.
See also
Programming analog modules (Page 5-31)
Diagnostics messages of analog output modules (Page 5-33)
