6.15 Analog IO module SM 334; AI 4/AO 2 x 8/8 Bit; (6ES7334-0CE01-0AA0)
S7-300 Automation System Module data
6-136 Manual, 08/2006, A5E00105505-04
Technical data
Load impedance (in the rated output range)
• For voltage outputs
– capacitive load
• For current outputs
– inductive load
min. 5 kΩ
max. 1 µF
max. 300 Ω
max. 1 mH
Voltage output
• Short-circuit protection
• Short-circuit current
Yes
max. 11 mA
Current output
• Noload voltage
max. 15 V
Destruction limit against external voltages/currents
• Voltage at outputs to MANA
• Current
max. 15 V, continuous
max. 50 mA d.c.
Wiring the actuators
• for voltage output
2-wire connection
4-wire connection (measuring line)
with 20-pin front connector
supported
not supported
6.15.1 Operating principle of SM 334; AI 4/AO 2 x 8/8 Bit
Introduction
SM 334; AI 4/AO 2 x 8/8 bit is a non-isolated analog IO module. SM 334; AI 4/AO 2 x 8/8 Bit
is not programmable.
Addressing
The inputs and outputs of the module are addressed beginning at the module start address.
The address of a channel is derived from the module start address and an address offset.
Input addresses
Addresses applicable to the inputs:
Channel Address
0 Module start address
1 Module start address + 2 bytes address offset
2 Module start address + 4 bytes address offset
3 Module start address + 6 bytes address offset
