Digital modules
3.32 Digital IO module SM 323; DI 16/DO 16 x DC 24 V/0.5 A; (6ES7323-1BL00-0AA0)
S7-300 Automation System Module data
3-112 Manual, 08/2006, A5E00105505-04
3.32 3.32 Digital IO module SM 323; DI 16/DO 16 x DC 24 V/0.5 A;
(6ES7323-1BL00-0AA0)
Order number
6ES7323-1BL00-0AA0
Properties
Properties of SM 323; DI 16/DO 16 x DC 24 V/0.5 A:
● 16 inputs, electrically isolated in groups of 16
● 16 outputs, electrically isolated in groups of 8
● Rated input voltage 24 VDC
● Rated load voltage 24 VDC
● Inputs suitable for switches and 2-/3-/4-wire proximity switches (BEROs)
● Outputs suitable for solenoid valves, DC contactors and indicator lights
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24-V power supply to SM 323; DI 16/DO
16 x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of approx. 50 µs, due to
the circuit structure.
