Analog modules
6.13 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0)
S7-300 Automation System Module data
6-116 Manual, 08/2006, A5E00105505-04
6.13 6.13 Analog output module SM 332; AO 4 x 12 Bit;
(6ES7332-5HD01-0AB0)
Order number
6ES7332-5HD01-0AB0
Properties
● 4 outputs in one group
● The output can be selected by individual channel
– Voltage output
– Current output
● Resolution 12 bits
● Programmable diagnostics and diagnostic interrupt
● Electrically isolated to backplane bus interface and load voltage
Diagnostics
For information on diagnostics message consolidated at the "group diagnostics" parameter,
refer to the table
Diagnostics messages of analog output modules
.
Terminal assignment
The following diagrams show wiring examples.
Note
When you switch the rated load voltage (L+) off and on, the output may carry incorrect
interim values for the duration of approx. 10 ms.
