Analog modules
6.14 Analog output module SM 332; AO 2 x 12 Bit; (6ES7332-5HB01-0AB0)
S7-300 Automation System Module data
6-128 Manual, 08/2006, A5E00105505-04
6.14.1 Output ranges SM 332; AO 2 x 12 Bit
Introduction
You can configure the outputs for operation as voltage or current outputs, or disable these.
You configure the outputs at the "output type" parameter in
STEP 7
.
The output type "Voltage" and output range "± 10 V" are set by default at the module. You
can always use this combination of output type and range without having to program the SM
332; AO 2 x 12 Bit in
STEP 7
.
Output ranges
You program the output ranges for voltage and current outputs in
STEP 7
.
Table 6-38 Output ranges SM 332; AO 2 x 12 Bit
Selected type of output Output range
Voltage 1 V to 5 V
0 V to 10 V
± 10 V
Current 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
6.14.2 Adjustable parameters
Introduction
For general information on programming analog modules, refer to the chapter
Programming
analog modules
.
The table below provides an overview of configurable parameters, including defaults:
Table 6-39 Summary of parameters SM 332; AO 2 x 12 Bit
Parameters Range of values Default Parameter
type
Scope
Enable
Diagnostic interrupt
Yes/no
No
Dynamic
Module
Diagnostics
Group diagnostics
Yes/no
No
static
Channel
Output
Output type
Output range
disabled
Voltage
Current
See table of
Output ranges for SM 332;
AO 2 x 12 Bit
V
± 10 V
Dynamic Channel
Reaction to CPU STOP ASS
HLV
SSV
Outputs zero
current/voltage
Hold last value
Set substitution
value
ASS Dynamic Channel
