Digital modules
3.23 Digital output module SM 322; DO 8 x DC 24 V/ 2 A; (6ES7322-1BF01-0AA0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
3-69
3.23 3.23 Digital output module SM 322; DO 8 x DC 24 V/ 2 A;
(6ES7322-1BF01-0AA0)
Order number
6ES7322-1BF01-0AA0
Properties
Properties of SM 322; DO 8 x DC 24 V/2 A:
● 8 outputs, electrically isolated in groups of 4
● Output current 2 A
● Rated load voltage 24 VDC
● suitable for solenoid valves, DC contactors and signal lamps
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24-V power supply to SM 322; DO
8 x DC 24 V/2 A, its outputs will carry "1" signal for the duration of approx. 50 µs, due to the
circuit structure.
