Interface modules
8.2 Interface module IM 360; (6ES7360-3AA01-0AA0)
S7-300 Automation System Module data
8-2 Manual, 08/2006, A5E00105505-04
8.2 8.2 Interface module IM 360; (6ES7360-3AA01-0AA0)
Order number
6ES7360-3AA01-0AA0
Properties
Special features of interface module IM 360:
Interface for rack 0 of the S7-300
Data transfer from IM 360 to IM 361 via connecting cable 368
Maximum distance between IM 360 and IM 361 is 10 m
Status and error LEDs
Interface module IM 360 is equipped with the following status and error LEDs.
Display element Meaning Explanations
SF Group error The LED lights up if
the connecting cable is missing.
IM 361 is switched off.
