Power supply modules
2.2 Power supply module PS 307; 2 A; (6ES7307-1BA00-0AA0)
S7-300 Automation System Module data
2-4 Manual, 08/2006, A5E00105505-04
Technical data
Output current
• Rated value
2 A;
1)
parallel connection supported
Short-circuit protection electronic, non-latching, 1.65 to 1.95 x I
N
Residual ripple max. 150 mV
pp
Electrical parameters
Safety class to IEC 536 (DIN VDE 0106, Part 1) I, with protective conductor
Isolation rating
• Rated isolation voltage (24 V to input)
150 VAC
• Test voltage
2800 VDC
Safety isolation SELV circuit
Buffering of power supply failure (at 24/48/72/96/110 V) > 10 ms
• Repeat rate
min. 1 s
Efficiency 75 %
Power consumption 64 W
Power loss 16 W
Diagnostics
"Output voltage present" display yes, green LED
1)
at a limited input voltage range > 24 V (DC 24 ... 138 V), PS 305 can be loaded to 3 A.
2.2 2.2 Power supply module PS 307; 2 A; (6ES7307-1BA00-0AA0)
Order number
6ES7307-1BA00-0AA0
Properties
Properties of the PS 307; 2 A power supply module:
● Output current 2 A
● Output voltage 24 VDC; short circuit-proof, open circuit-proof
● Connection to singlephase AC mains
(rated input voltage 120/230 VAC, 50/60 Hz)
● Safety isolation to EN 60 950
● May be used as load power supply
