Parameter sets of signal modules
A.8 Parameters of analog input module SM 331; AI 8 x 16 Bit
S7-300 Automation System Module data
A-30 Manual, 08/2006, A5E00105505-04
Structure of data record 1
The figure below shows the structure of data record 1 for the parameters of the electrically
isolated analog input module SM 331; AI 8 x 16 bit.
You enable a parameter by setting a logical "1" at the corresponding bit in byte 0.

&\FOHHQGLQWHUUXSWHQDEOH
'LDJQRVWLFVLQWHUUXSWHQDEOH
+DUGZDUHLQWHUUXSWZKHQOLPLWH[FHHGHG
%\WHVWRDUHQRWDVVLJQHG
%\WH
%LWQXPEHU
Figure A-15 Data record 1 for parameters of SM 331; AI 8 x 16 Bit
