Analog modules
6.6 Analog input module SM 331; AI 8 x 13 Bit;(6ES7331-1KF01-0AB0)
S7-300 Automation System Module data
6-44 Manual, 08/2006, A5E00105505-04
Technical data
Operational limit (across temperature range, relative to input range)
± 0,6 %
• Voltage input
± 5 V
± 10 V
1 V to 5 V
0 V to 10 V
± 50 mV
± 500 mV
± 1 V
± 0,5 %
• Current input
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
± 0,5 %
• Resistance
0 kΩ to 6 kΩ
0 Ω to 600 Ω
± 0.5 %
± 0.5 %
Pt 100
Ni 100
Standard
± 1,2 K
Pt 100
Ni 100
Klima
± 1 K
Ni 1000,
LG-Ni 1000
Standard
± 1 K
• Resistance thermometers
Ni 1000
LG-Ni 1000
Klima
± 1 K
Basic error limit (operational error limit at 25 °C, relative to input range)
± 0,4 %
• Voltage input
± 5 V
± 10 V
1 V to 5 V
0 V to 10 V
± 50 mV
± 500 mV
± 1 V
± 0,3 %
• Current input
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
± 0,3 %
• Resistance
0 kΩ to 6 kΩ
0 Ω to 600 Ω
± 0,3 %
± 0,3 %
Pt 100
Ni 100
Standard
± 1 K
Pt 100
Ni 100
Klima
± 0.8 K
Ni 1000
LG-Ni 1000
Standard
± 0.8 K
• Resistance thermometers
Ni 1000
LG-Ni
1000 Klima
± 0.8 K
