2.2 Power supply module PS 307; 2 A; (6ES7307-1BA00-0AA0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
2-7
Technical data of PS 307; 2 A (6ES7307-1BA00-0AA0)
Technical data
Dimensions and weight
Dimensions W x H x D (mm) 50 x 125 x 120
Weight approx. 420 g
Input parameters
Input voltage
• Rated value
Mains frequency
• Rated value
• Permissible range
AC 120 V/230 V
50 Hz or 60 Hz
47 Hz to 63 Hz
Rated input current
• at 230 V
• at 120 V
0.5 A
0.8 A
Inrush current (at 25 °C) 20 A
I
2
t (at inrush current) 1 A
2
s
Output parameters
Output voltage
• Rated value
• Permissible range
• Rampup time
24 VDC
24 V ± 5 %, open circuit-proof
max. 2.5 s
Output current
• Rated value
2 A,
parallel wiring not supported
Short-circuit protection electronic, non-latching
1.1 to 1.3 x I
N
Residual ripple max. 150 mV
pp
Electrical parameters
Safety class to IEC 536 (DIN VDE 0106, Part 1) I, with protective conductor
Isolation rating
• Rated insulation voltage
(24 V to L1)
• Test voltage
AC 250 V
DC 2800 V
Safety isolation SELV circuit
Buffering of power supply failure (at 93 V or 187 V)
• Repeat rate
min. 20 ms
min 1 s
Efficiency 83 %
Power consumption 58 W
Power loss typ. 10 W
Diagnostics
"Output voltage present" display yes, green LED
