Dimensional drawings
C.2 Dimensional drawings of the power supply modules
S7-300 Automation System Module data
C-10 Manual, 08/2006, A5E00105505-04
PS 307; 5 A with 313/314/315/ 315-2 DP CPU
The figure below shows the dimensional drawing of power supply module PS 307; 5 A with
313/314/315/315-2 DP CPU in the side view.




Figure C-14 Dimensional drawing power supply module PS 307; 5 A with CPU 313/314/315/315-2
DP, side view
