Overview
1.3 Wireless Teach Pendant F IWLAN
Wireless Teach Pendant F IWLAN V2
14 Operating Instructions, 08/2010, A5E02453837-01
1.3 Wireless Teach Pendant F IWLAN
Front view and side view
① Rotary switch
② EMERGENCY STOP button
③ Illuminated pushbutton
④ Display with touch screen
⑤ LED display
⑥ Carrying strap
⑦ Safety bar
⑧ Membrane keyboard
⑨ Enabling button
⑩ Grip straps, left or right on the HMI device for securing
