Siemens F IWLAN - Showing the Battery Charge

Mounting and connection
4.5 Connecting the HMI device
Wireless Teach Pendant F IWLAN V2
76 Operating Instructions, 08/2010, A5E02453837-01
Procedure – Disconnecting the charger
Proceed as follows:
1. Pull the plug of the power cable out of the charger's socket.
The "POWER" LED goes out.
2. Disconnect the power supply from the mains.
4.5.6.4 Showing the battery charge
The main rechargeable battery features an LED array. The respective LEDs indicate the
battery charge.
.H\
/('DUUD\
FRQVLVWLQJRIILYH/('V
Requirement
● The main rechargeable battery is removed from the HMI device.
Procedure
Proceed as follows:
1. Press the button.
The LED lights when the button is released after approx. 5 seconds.
The number of illuminated LEDs indicates the charge status.
Number of LEDs Flashes for Lights for
1 0 to 19 % of the charge capacity 20 to 39 % of the charge capacity
2 - 40 to 59 % of the charge capacity
3 - 60 to 79 % of the charge capacity
4 - 80 to 96 % of the charge capacity
5 - 97 to 100 % of the charge capacity
If all the LEDs light up, the main rechargeable battery is fully charged.
Note
This applies to rechargeable batteries that are stored – read the section "Maintenance and
care (Pag
e 237)".
PRELIMINARY II
1.7.2010
