4.4 Connecting the docking station and charger
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
65
4.4 Connecting the docking station and charger
The power supply provides electricity to the docking station and charger.
NOTICE
Use only approved power supplies
If you use an unapproved power supply, damage may occur to the HMI device.
Only use the power supply approved for the HMI device.
Danger of overheating
There is danger of overheating if you cover the power supply and thereby inhibit the air
circulation.
Do not cover the power supply unit.
Note
Unplug the mains connector of the power supply to ensure complete electrical isolation.
The power supply is designed for operation on grounded power supply networks (TN
systems to VDE 0100, Part 300, or IEC 364-3).
Operation is not authorized on ungrounded or impedance-grounded power networks (IT
systems).
Read the section "ESD guideline (Page 251)".
Requirement
● The docking station is installed or the charger is ready for operation.
● The power supply is ready.
Procedure – disconnection
Proceed as follows:
1. Store the power supply unit in a safe place.
2. Insert the plug of the 24 V power cable into the socket of the docking station or charger.
3. Connect the power supply unit to the mains.
Procedure – disconnection
Proceed as follows:
1. Pull the plug of the 24 V power cable out of the socket of the docking station or out of the
charger.
2. Disconnect the power supply unit from the mains.
See also
Power supply unit (Page 19)
