Mounting and connection
4.5 Connecting the HMI device
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
71
4.5.5 Connecting the rechargeable buffer battery
Before you begin operation of the HMI device, you need to connect the rechargeable buffer
battery.
You can only replace the main rechargeable battery without switching off the HMI device
when the rechargeable buffer battery is connected.
Procedure
Note
Read the following sections:
"Opening and closing the terminal compartment (Page 67)"
"Safety instructions (Page 72)".
Proceed as follows:
1. Open the connection compartment.
2. Plug the connector if the cable into the socket on the printed circuit board.
5HFKDUJHDEOHEXIIHUEDWWHU\
&RQQHFWLQJFDEOH
3OXJDQGVRFNHW
3ULQWHGFLUFXLWERDUG
3. Position the cable so that it is not pinched when you close the connection compartment.
4. Close the connection compartment.
