Overview
1.6 Equipment for HMI device and plant
Wireless Teach Pendant F IWLAN V2
18 Operating Instructions, 08/2010, A5E02453837-01
① Retention latch
② Mounting hole, left and right
③ Charge contact
④ Connection socket for the power unit (on the bottom)
Read the relevant documentation.
1.6.3 Charger°
The charger is used to charge and store the main batteries for the
Wireless Teach Pendant F IWLAN. You can charge one main battery in each of the two
charger sections.
NOTICE
Chargers suited for office environments only
If you use the charger in ambient conditions that do not correspond to an office
environment, malfunctions may occur.
Use the charger only in an office environment.
