Planning the use
3.8 Planning the installation location of signal lamps
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
57
Maintaining clearances
The following clearance is required around the docking station:
$OOGLPHQVLRQVLQPP
3.8 Planning the installation location of signal lamps
You will need a signal lamp for a machine operated in fail-safe mode with the enabling
button. The signal lamp notifies the operator that he/she has logged on to the machine.
Plan a clearly visible installation location for the signal lamp that is assigned to a machine.
