Safety instructions and standards
2.9 Transport and storage conditions
Wireless Teach Pendant F IWLAN V2
46 Operating Instructions, 08/2010, A5E02453837-01
2.9 Transport and storage conditions
The shipping conditions of this HMI device exceed requirements in accordance with IEC
61131-2. The following specifications apply to devices that are shipped and stored in the
original packaging.
● The mechanical conditions are compliant with IEC 60721-3-2, Class 2M2.
The following table shows the transport and storage conditions for the HMI device, docking
station, power supply unit and RFID tag.
Type of condition Permitted range
Drop test (in transport package) ≤ 1 m
Temperature –20 to +60 °C
Atmospheric pressure 1140 hPa to 660 hPa,
corresponds to an elevation of –1000 to 3500 m
Relative humidity Applies to HMI device:
10 to 90%, without condensation
Applies to docking station:
35 to 85%, without condensation
Sinusoidal vibration in accordance with
IEC 60068-2-6
5 Hz to 9 Hz: 3.5 mm
9 Hz to 500 Hz: 9.8 m/s
2
Shock in accordance with IEC 60068-2-29 250 m/s
2
, 6 ms, 1000 shocks
NOTICE
Equipment failure
Moisture in the form of condensation on or in the device is formed:
When transporting a device at low temperatures
Under extreme temperature variations
Moisture and condensation lead to malfunction.
Bring the device to room temperature before operating.
Condensation
When condensation is on the device, do not expose the HMI device to direct radiation from
a heater.
If condensation has developed, wait approximately 4 hours until the HMI device has dried
completely before switching it on.
The following points must be adhered to in order to ensure a fault-free and safe operation of
the HMI device:
● Proper transportation and storage
● Proper installation and mounting
● Careful operation and maintenance
The warranty for the HMI device will be deemed void if these stipulations are not heeded.
