Safety instructions and standards
2.8 Electromagnetic compatibility
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
45
Sinusoidal interference
The following table shows the EMC behavior of the modules with respect to sinusoidal
interference.
The table applies to the HMI device, docking station and power supply.
Sinusoidal interference Test values Degree of
severity
HF radiation (in electromagnetic
fields) in accordance with
IEC 61000-4-3
80% amplitude modulation at 1 kHz
Up to 10 V/m in the 80 MHz to 1 GHz range
Up to 10 V/m in the 1.4 GHz to 2 GHz range
Up to 1 V/m in the 2 GHz to 2.7 GHz range
3
RF interference current on
cables and cable shielding
conforming to IEC 61000-4-6
Test voltage 10 V, with 80% amplitude modulation
of 1 kHz in the 9 kHz to 80 MHz range
3
Emission of radio interference
The following table shows the interference emissions from electromagnetic fields in
accordance with EN 55016, Limit Value Class A, Group 1, measured at a distance of 10 m.
30 to 230 MHz < 40 dB (V/m) quasi-peak
230 to 1 000 MHz < 47 dB (V/m) quasi-peak
Note
Before you connect the HMI device to the public electrical network, ensure that it is
compliant with Limit Value Class B in accordance with EN 55022.
