Siemens F IWLAN - Connecting the Configuration PC

Mounting and connection
4.5 Connecting the HMI device
Wireless Teach Pendant F IWLAN V2
78 Operating Instructions, 08/2010, A5E02453837-01
4.5.8 Connecting the configuration PC
You have the following options for connecting a configuration PC to the HMI device:
● Connection via WLAN
● Connection via LAN and RJ45 interface
● Connection via USB
Configuration graphic
The following figure illustrates the options for connection between the HMI device and the
configuration PC.
(WKHUQHW
(WKHUQHW
86%
