Siemens F IWLAN - Operator Controls; Operating the Rotary Switch; Operating the Illuminated Push-Button; Evaluating Operator Controls

Operator controls and displays
5.5 Operator controls
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
93
5.5 Operator controls
5.5.1 Operating the rotary switch
The rotary switch has two positions. The function of the rotary switch is defined in the current
project. Refer to the plant documentation for additional information on the function.
5RWDU\VZLWFK
5.5.2 Operating the illuminated push-button
The function of the illuminated pushbutton is defined in the current project. Refer to the plant
documentation for additional information on the function.
,OOXPLQDWHGSXVKEXWWRQ
5.5.3 Evaluating operator controls
5.5.3.1 Overview
The following information can be obtain between the Wireless Teach Pendant F IWLAN and
PLC:
● Control state of the rotary switch
● Control state of the illuminated pushbutton
● Signal status of the LEDs
There are two ways of transferring information:
● Direct keys
● System functions of WinCC flexible
Note
The following sections are intended for the configuration engineer.
