Siemens F IWLAN - Connecting the PLC

Mounting and connection
4.5 Connecting the HMI device
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
77
4.5.7 Connecting the PLC
Only use approved components to connect a SIMATIC S7 PLC. You can find more
information on this on the Internet in Industry Mall (http://mall.automation.siemens.com
).
Configuration graphic
The following figure shows the connection between the PLC and the HMI device.
(WKHUQHW
6,0$7,&6)
6,0$7,&6
See also
System manual "Basics on Setting up an Industrial Wireless LAN"
(http://support.automation.siemens.com/WW/view/en/9975764
)
PRELIMINARY II
1.7.2010
