Overview
1.9 Supported WinCC flexible objects
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
23
1.9 Supported WinCC flexible objects
The following tables contain the maximum number of objects you can use with the HMI
device in a project.
Note
The maximum number of multiple objects used simultaneously can affect the performance of
the active WinCC flexible project.
Alarms
Object Specification HMI device
Number of discrete alarms 4 000
Number of analog alarms 200
Length of the alarm text 80 characters
Number of tags in an alarm Max. 8
LEDs Alarm line, Alarm window,
Alarm view
Acknowledge error alarms individually Yes
Acknowledge several error alarms
simultaneously (group acknowledgment of
alarm groups)
16 alarm groups
Edit alarm Yes
Alarm
Alarm indicator Yes
ALARM_S Display S7 alarms Yes
Alarm buffer capacity 512 alarms
Simultaneously queued alarm events Max. 250
View alarm Yes
Delete alarm buffer Yes
Alarm buffer, retentive
Line-by-line printing of alarms Yes
Tags, values and lists
Object Specification HMI device
Tag Number 2 048
Limit value monitoring Input/Output Yes
Linear scaling Input/Output Yes
Text list Number 500
1)
Graphics list Number 400
1)
1)
The maximum total of text and graphics lists is 500.
