Overview
1.9 Supported WinCC flexible objects
Wireless Teach Pendant F IWLAN V2
24 Operating Instructions, 08/2010, A5E02453837-01
HMI screens
Object Specification HMI device
Number 500
Fields per screen 200
Tags per screen 200
Complex objects per screen (for example
bars)
10
Screen
Template Yes
Recipes
Object Specification HMI device
Number 300
Data records per recipe 500
Entries per recipe 1 000
Recipe memory 64 KB
Recipe
Location
1)
Memory card
USB stick
Network drive
1)
The number of recipe data records might be restricted by the capacity of the storage
medium.
Logs
NOTICE
Logging
The HMI device is suitable for logging small volumes of data. The use of a large circular log
has a negative effect on performance.
In order to log larger amounts of data, use segmented circular logs with multiple sequential
logs.
Object Specification HMI device
Number of logs 20
Number of partial logs in a segmented
circular log
400
Entries in each log including all partial logs 10 000
Filing format CSV with ANSI character set
Logs
Location
1)
Memory card
USB stick
Network drive
1) The number of entries in the log may be restricted by the capacity of the storage
medium.
