Siemens F IWLAN - Safety-Related Operator Controls; EMERGENCY STOP Button

Operator controls and displays
5.4 Safety-related operator controls
Wireless Teach Pendant F IWLAN V2
88 Operating Instructions, 08/2010, A5E02453837-01
Power management for the HMI device provides the following operating modes:
Operating
mode
LED Action Follow-up operating
mode
OFF "PWR" is off.
"BAT" is off.
Briefly press Taste "ON/OFF" ON
Automatically, if no actions are
performed within a configured
time period.
"Power Save 1"
Briefly press Taste "ON/OFF" "Power Save 2"
ON "PWR" lights up.
Press Taste "ON/OFF" for at
least 4 seconds.
OFF
Operation on the touch screen ON
Briefly press Taste "ON/OFF" "Power Save 2"
Automatically, after a configured
time interval if no operations are
carried out
"Power Save 2"
"Power Save 1" "PWR" lights up.
The brightness of the
touch screen is reduced.
Press Taste "ON/OFF" for at
least 4 seconds.
OFF
Briefly press Taste "ON/OFF" ON "Power Save 2" "PWR" flashes.
The touch screen is
switched off.
Briefly press Taste "ON/OFF"
and then press it for at least
4 seconds.
OFF
See also
Setting the screen saver (Page 127)
5.4 Safety-related operator controls
5.4.1 EMERGENCY STOP button
The EMERGENCY STOP button is designed with 2-channels and enables an EMERGENCY
STOP of the plant unit with which safety-related communication is taking place. The
EMERGENCY STOP button satisfies the requirements specified in DIN IEC 60947-5-5,1997
Annex K. You can find additional information in the section "Safety functions of the
EMERGENCY STOP button (Pag
e 41)".
(PHUJHQF\VWRSEXWWRQ
Due to its position, the EMERGENCY STOP button is equally accessible for both left-handed
and right-handed persons.
