Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
97
Configuring the HMI device
6
6.1 Desktop and Loader
Once the HMI device is switched on and booted, the display shows the desktop with the
Loader.
① Desktop
② Loader
③ Start menu
④ Icon for screen keyboard
⑤ Icon for displaying IP information about the WLAN/LAN connection
