Planning the use
3.2 Operating conditions
Wireless Teach Pendant F IWLAN V2
Operating Instructions, 08/2010, A5E02453837-01
49
Testing mechanical ambient conditions
The following table provides information on the type and scope of tests for mechanical
ambient conditions performed for the HMI device.
Test Physical variable Value
Vibration 1 octave/min
10 cycles per axis
5 to 8.4 Hz:
Deflection 3.5 mm
Vibrations
IEC 60068-2-6
Test Fc
Frequency band
8.4 to 150 Hz
Vibration acceleration 9.8 m/s
Shock form Half sine
Shock amplitude 15 g
Shock duration 11 ms
Shock
IEC 60068-2-27
Number of shocks 3 per axis
Impact
IEC 60068-2-75
Impact stress 1 Nm, once
With an impact test device similar to
DIN VDE 0740, Part 1, Section 19.2 at
room temperature.
Drop test
EN 60068-2-31
Fall height 0.5 m
Applies to the HMI device, with and
without battery
Climatic ambient conditions for the HMI device
The following table shows the permitted ambient climatic conditions for use of the HMI
device.
Ambient condition Permitted range Comment
Operating temperature 0 to 40° C –
Humidity, relative 5 to 85 %,
no condensation
Stress level 2,
according to IEC 61131-2
Humidity, absolute 1 to 25 g/m
3
–
Atmospheric pressure 1060 to 700 hPa Corresponds to an
elevation of –1000 to 2000 m
SO
2
< 0.5 vpm,
relative humidity < 60%,
no condensation
Test: 10 cm
3
/m
3
; 10 days Pollutant concentration
H
2
S < 0.1 vpm,
relative humidity < 60%,
no condensation
Test: 1 cm
3
/m
3
; 10 days
