Mounting and connection
4.5 Connecting the HMI device
Wireless Teach Pendant F IWLAN V2
74 Operating Instructions, 08/2010, A5E02453837-01
Procedure
Proceed as follows:
1. Lay the HMI device on its front side.
CAUTION
Potential malfunction when HMI device switched on
If the HMI device is switched on and lying on its front, any one of the operator controls
can trigger a malfunction.
Make sure that no operator control can be triggered when the HMI device is laid down.
2. Slide the compartment cover in the direction of the arrow until it catches.
If you are using the HMI device for the first time, there is no main rechargeable battery in
the battery compartment.
%DWWHU\FRPSDUWPHQW
0DLQUHFKDUJHDEOHEDWWHU\
5LEERQ
&RPSDUWPHQWFRYHU
3. Remove the main rechargeable battery by pulling on the ribbon.
4. Insert a charged main rechargeable battery.
5. Close the compartment cover fully.
