Operator controls and displays
5.1 Overview
Wireless Teach Pendant F IWLAN V2
84 Operating Instructions, 08/2010, A5E02453837-01
NOTICE
Damage to the membrane keyboard
Do not touch the keys with a pointed or sharp object. Avoid applying sudden pressure to
the keys with a hard object. Both of these will substantially reduce the service life of the
membrane keyboard and can even lead to total failure.
Only use your fingers to operate the HMI device buttons.
The functions assigned to the keys of the membrane keyboard are defined during
configuration. Outside of the project, the keys of the membrane keyboard have no function.
Displays and other operator controls
● LED display
● EMERGENCY STOP button
● Enabling button
● Rotary switch
● Illuminated pushbutton
