Programming Manual of FC2005/FC901
A6V10333724_b_en_-- 45|63
Silenceable On
Waterflow
(output channel)
Available when “Silenceable” (output channel) is set as True.
Bool: True (default) / False
HoldThroughReset
(output channel)
Device won’t be reset when press Reset button on the panel.
Bool: True / False (default)
HTRI-M Name Name of the device
Name Addition Addition description of the device; max. 20 characters
Address Range: 1...50. System assigns one address automatically once
a device is added.
Turn Off Bool: True / False (default)
Input Closed
(Input)
Bool: True / False (default)
Normally Open
(Input)
Bool: True (default) / False
HCP Name Name of the device
Name Addition Addition description of the device; max. 20 characters
Address Range: 1...50.
System assigns one address automatically once a device is
added.
Turn Off Bool: True / False (default)
Silenceable
(Intelligent Control)
Bool: True (default) / False
Silenceable On
Waterflow
(Intelligent Control)
Available when “Silenceable” (output channel) is set as True.
Bool: True (default) / False
HoldThroughReset
(Intelligent Control)
Device won’t be reset when press Reset button on the panel.
Bool: True / False (default)
OOH941
OOHC941
(Only available for
FC901)
Name Name of the device
Name Addition Additional description of the device; max. 20 characters
Address Range: 1...50; System assigns one address automatically once
a device is added.
LED normal off Bool: True / False (default)
LED Activation Input Only (default)
Input or Output
Audible Base Type Unknown (default)
ABHW-4B
ABHW-4S
Buzzer Base Powering Available when “ABHW-4B” is selected for “Audible Base Type”:
Detection Line Powered
NAC Powered
AUX/DC Powered (default)
Speaker Base
Powering
Available when “ABHW-4S” is selected for “Audible Base Type”:
NAC Powered
AUX/DC Powered (default)
Turn Off Bool: True/ False (default)
