Siemens FC2005 Programming Manual

Programming Manual of FC2005/FC901
48|63 A6V10333724_b_en_--
Address Range: 1...50; System assigns one address automatically once
a device is added.
LED Normal Off Bool: True/ False (default)
LED Activation Input Only (default)
Input or Output
Wire Style Option 1: Class A
Option 2: Class B (default)
Turn Off Bool: True/ False (default)
Isolator Support When set as True, the device should be wired according to the
rules for isolator supported. Otherwise, the panel reports
trouble. When set as False (default), the device should be wired
as polar non-sensitive. Otherwise, the panel reports trouble as
well.
Input Closed
(input channel)
Bool: True/ False (default)
Normally Open
(input channel)
Bool: True (default) / False
Monitoring
(input channel)
Option 1: Open Only (default)
Option 2: Open and short
Sensoractivationdelay
(input channel)
Range: 0.25 s (default)…240 s (select one option from the list)
Silenceable
(output channel)
Bool: True/ False (default)
Silenceable On
Waterflow
(output channel)
Available when “Silenceable” (output channel) is set as True.
Bool: True (default) / False
Normally Open
(output channel)
Bool: True (default) / False
Signal Shape
(output channel)
Static (default)
Pulse
Pulse Mode
(output channel)
Available when “Signal Shape” (output channel) is set to “Pulse”.
Range: 1…20 s
Select one option from the drop-down list.
Failsafe Position
(output channel)
Off (default)
Inactive
Active
HoldThroughReset
(output channel)
Device won’t be reset when press Reset button on the panel.
Bool: True / False (default)
OP921
(Only available for
FC901)
Name Name of the device
Name Addition Additional description of the device; max. 20 characters
Address Range: 1...50; System assigns one address automatically once
a device is added.
LED Normal Off Bool: True/ False (default)
LED Activation Input Only (default)
Input or Output
Audible Base Type Unknown (default)
