Operation
5
Switching between 'Manned' / 'Unmanned' operation modes
123
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
Switching the operation mode on the touch screen
All 'Areas'
w You are logged onto at least 'Access level' 2.1.
1. Press the 'Manned/unmanned states' tab
a The 'Manned/unmanned states' event list opens.
2. Press 'ALL areas to UNMANNED' in the event command list (ECL).
a The command execution display confirms successful execution of the
command by displaying .
a The 'Areas' are switched.
Individual 'Area'
w You are logged onto at least 'Access level' 2.1.
1. Press the 'Manned/unmanned states' tab.
a The 'Manned/unmanned states' event list opens.
2. Highlight a 'Area'.
a The highlighted list entry is displayed in yellow.
3. Press 'Options' in the ECL.
a The 'Select option' dialog window opens.
4. Select the 'Execute commands' menu item.
a The 'Select command' dialog window opens.
5. Select the 'Switch to UNMANNED' command.
a The command execution display confirms successful execution of the
command by displaying .
a The 'Area' is switched to 'unmanned' operation mode.
